Effects

Effects are used in OpenShot to enhance or modify the audio or video of a clip. They can modify pixels and audio data, and can generally enhance your video projects. Each effect has its own set of properties, most of which can be animated over time, for example varying the Brightness & Contrast of a clip over time.

Effects can be added to any clip by dragging and dropping them from the Effects tab onto a clip. Each effect is represented by a small colored icon and the first letter of the effect name. Note: Pay close attention to where the play-head (i.e. red playback line) is. Key frames are automatically created at the current playback position, to help create animations quickly.

To view an effect’s properties, right-click on the effect icon, revealing the context menu, and choose Properties. The property editor will appear, where you can edit these properties. Properties appear alphabetically in the dock, with filter options available at the top. See Clip Properties.

To adjust a property:

  • Drag the slider for coarse changes.

  • Double-click to enter precise values.

  • Right/double-click for non-numerical options.

Effect properties are integral to the Animation system. When you modify an effect property, a keyframe is generated at the current playhead position. For a property to span the entire clip, position the playhead at or before the clip’s start before making adjustments. A convenient way to identify a clip’s start is by utilizing the ‘next/previous marker’ feature on the Timeline toolbar.

_images/clip-effects.jpg

List of Effects

OpenShot Video Editor has a total of 27 built-in video and audio effects: 18 video effects and 9 audio effects. These effects can be added to a clip by dragging the effect onto a clip. The following table contains the name and short description of each effect.

Effect Name

Effect Description

Alpha Mask / Wipe Transition

Grayscale mask transition between images.

Bars

Add colored bars around your video.

Blur

Adjust image blur.

Brightness & Contrast

Modify frame’s brightness and contrast.

Caption

Add text captions to any clip.

Chroma Key (Greenscreen)

Replace color with transparency.

Color Saturation

Adjust color intensity.

Color Shift

Shift image colors in various directions.

Crop

Crop out parts of your video.

Deinterlace

Remove interlacing from video.

Hue

Adjust hue / color.

Negative

Produce a negative image.

Object Detector

Detect objects in video.

Pixelate

Increase or decrease visible pixels.

Shift

Shift image in different directions.

Stabilizer

Reduce video shake.

Tracker

Track bounding box in video.

Wave

Distort image into a wave pattern.

Compressor

Reduce loudness or amplify quiet sounds.

Delay

Adjust audio-video synchronism.

Distortion

Clip audio signal for distortion.

Echo

Add delayed sound reflection.

Expander

Make loud parts relatively louder.

Noise

Add random equal-intensity signals.

Parametric EQ

Adjust frequency volume in audio.

Robotization

Transform audio into robotic voice.

Whisperization

Transform audio into whispers.

Effect Properties

Below is a list of common effect properties, shared by all effects in OpenShot. To view an effect’s properties, right click and choose Properties. The property editor will appear, where you can change these properties. Note: Pay close attention to where the play-head (i.e. red playback line) is. Key frames are automatically created at the current playback position, to help quickly create animations.

See the table below for a list of common effect properties. Only the common properties that all effects share are listed here. Each effect also has many unique properties, which are specific to each effect, see Video Effects for more information on individual effects and their unique properties.

Effect Property Name

Type

Description

Duration

Float

The length of the effect (in seconds). Read-only property. Most effects default to the length of a clip. This property is hidden when an effect belongs to a clip.

End

Float

The end trimming position of the effect (in seconds). This property is hidden when an effect belongs to a clip.

ID

String

A randomly generated GUID (globally unique identifier) assigned to each effect. Read-only property.

Parent

String

The parent object to this effect, which makes many of these keyframe values initialize to the parent value.

Position

Float

The position of the effect on the timeline (in seconds). This property is hidden when an effect belongs to a clip.

Start

Float

The start trimming position of the effect (in seconds). This property is hidden when an effect belongs to a clip.

Track

Int

The layer which holds the effect (higher tracks are rendered on top of lower tracks). This property is hidden when an effect belongs to a clip.

Duration

The Duration property is a float value indicating the length of the effect in seconds. This is a Read-only property. This is calculated by: End - Start. To modify duration, you must edit the Start and/or End effect properties.

NOTE: Most effects in OpenShot default the effect duration to the clip duration, and hide this property from the editor.

End

The End property defines the trimming point at the end of the effect in seconds, allowing you to control how much of the effect is visible in the timeline. Changing this property will impact the Duration effect property.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

ID

The ID property holds a randomly generated GUID (Globally Unique Identifier) assigned to each effect, ensuring its uniqueness. This is a Read-only property, and assigned by OpenShot when an effect is created.

Track

The Track property is an integer indicating the layer on which the effect is placed. Effects on higher tracks are rendered above those on lower tracks.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

Effect Parent

The Parent property of an effect sets the initial keyframe values to a parent effect. For example, if many effects all point to the same parent effect, they will inherit all their initial properties, such as font size, font color, and background color for a Caption effect. In the example of many Caption effects using the same Parent effect, it is an efficient way to manage a large number of these effects.

NOTE: The parent property for effects should be linked to the same type of parent effect, otherwise their default initial values will not match. Also see Clip Parent.

Position

The Position property determines the effect’s position on the timeline in seconds, with 0.0 indicating the beginning.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

Start

The Start property defines the trimming point at the beginning of the effect in seconds. Changing this property will impact the Duration effect property.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

Sequencing

Effects are normally applied before the Clip processes keyframes. This allows the effect to process the raw image of the clip, before the clip applies properties such as scaling, rotation, location, etc… Normally, this is the preferred sequence of events, and this is the default behavior of effects in OpenShot. However, you can optionally override this behavior with the Apply Before Clip Keyframes property.

If you set the Apply Before Clip Keyframes property to No, the effect will be sequenced after the clip scales, rotates, and applies keyframes to the image. This can be useful on certain effects, such as the Mask effect, when you want to animate a clip first and then apply a static mask to the clip.

Video Effects

Effects are generally divided into two categories: video and audio effects. Video effects modify the image and pixel data of a clip. Below is a list of video effects, and their properties. Often it is best to experiment with an effect, entering different values into the properties, and observing the results.

Alpha Mask / Wipe Transition

Uses a grayscale mask image to gradually wipe / transition between 2 images (only affects the image, and not the audio track)

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

brightness

(float, -1 to 1) This curve controls the motion across the wipe

contrast

(float, 0 to 20) This curve controls the hardness and softness of the wipe edge

reader

(reader) This reader can use any image or video as input for your grayscale wipe

replace_image

(bool, choices: ['Yes', 'No']) Replace the clips image with the current grayscale wipe image, useful for troubleshooting

Bars

Add colored bars around your video.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

bottom

(float, 0 to 0.5) The curve to adjust the bottom bar size

color

(color) The curve to adjust the color of bars

left

(float, 0 to 0.5) The curve to adjust the left bar size

right

(float, 0 to 0.5) The curve to adjust the right bar size

top

(float, 0 to 0.5) The curve to adjust the top bar size

Blur

Adjust the blur of the frame’s image.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

horizontal_radius

(float, 0 to 100) Horizontal blur radius keyframe. The size of the horizontal blur operation in pixels.

iterations

(float, 0 to 100) Iterations keyframe. The # of blur iterations per pixel. 3 iterations = Gaussian.

sigma

(float, 0 to 100) Sigma keyframe. The amount of spread in the blur operation. Should be larger than radius.

vertical_radius

(float, 0 to 100) Vertical blur radius keyframe. The size of the vertical blur operation in pixels.

Brightness & Contrast

Adjust the brightness and contrast of the frame’s image.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

brightness

(float, -1 to 1) The curve to adjust the brightness

contrast

(float, 0 to 100) The curve to adjust the contrast (3 is typical, 20 is a lot, 100 is max. 0 is invalid)

Caption

Add text captions on top of your video. We support both VTT (WebVTT) and SubRip (SRT) subtitle file formats. These formats are used to display captions or subtitles in videos. They allow you to add text-based subtitles to video content, making it more accessible to a wider audience, especially for those who are deaf or hard of hearing. The Caption effect can even animate the text fading in/out, and supports any font, size, color, and margin. OpenShot also has an easy-to-use Caption editor, where you can quickly insert captions at the playhead position, or edit all your caption text in one place.

Show a caption, starting at 5 seconds and ending at 10 seconds.
00:00:05.000 --> 00:00:10.000
Hello, welcome to our video!

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

background

(color) Color of caption area background

background_alpha

(float, 0 to 1) Background color alpha

background_corner

(float, 0 to 60) Background corner radius

background_padding

(float, 0 to 60) Background padding

caption_font

(font) Font name or family name

caption_text

(caption) VTT/Subrip formatted caption text (multi-line)

color

(color) Color of caption text

fade_in

(float, 0 to 3) Fade in per caption (# of seconds)

fade_out

(float, 0 to 3) Fade out per caption (# of seconds)

font_alpha

(float, 0 to 1) Font color alpha

font_size

(float, 0 to 200) Font size in points

left

(float, 0 to 0.5) Size of left margin

line_spacing

(float, 0 to 5) Distance between lines (1.0 default)

right

(float, 0 to 0.5) Size of right margin

stroke

(color) Color of text border / stroke

stroke_width

(float, 0 to 10) Width of text border / stroke

top

(float, 0 to 1) Size of top margin

Chroma Key (Greenscreen)

Replaces the color (or chroma) of the frame with transparency (i.e. keys out the color).

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

color

(color) The color to match

fuzz

(float, 0 to 125) The fuzz factor (or threshold)

halo

(float, 0 to 125) The additional threshold for halo elimination.

keymethod

(int, choices: ['Basic keying', 'HSV/HSL hue', 'HSV saturation', 'HSL saturation', 'HSV value', 'HSL luminance', 'LCH luminosity', 'LCH chroma', 'LCH hue', 'CIE Distance', 'Cb,Cr vector']) The keying method or algorithm to use.

Color Saturation

Adjust the color saturation.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

saturation

(float, 0 to 4) The curve to adjust the overall saturation of the frame’s image (0.0 = greyscale, 1.0 = normal, 2.0 = double saturation)

saturation_B

(float, 0 to 4) The curve to adjust blue saturation of the frame’s image

saturation_G

(float, 0 to 4) The curve to adjust green saturation of the frame’s image (0.0 = greyscale, 1.0 = normal, 2.0 = double saturation)

saturation_R

(float, 0 to 4) The curve to adjust red saturation of the frame’s image

Color Shift

Shift the colors of an image up, down, left, and right (with infinite wrapping).

Each pixel has 4 color channels:

  • Red, Green, Blue, and Alpha (i.e. transparency)

  • Each channel value is between 0 and 255

The Color Shift effect simply “moves” or “translates” a specific color channel on the X or Y axis. Not all video and image formats support an alpha channel, and in those cases, you will not see any changes when adjusting the color shift of the alpha channel.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

alpha_x

(float, -1 to 1) Shift the Alpha X coordinates (left or right)

alpha_y

(float, -1 to 1) Shift the Alpha Y coordinates (up or down)

blue_x

(float, -1 to 1) Shift the Blue X coordinates (left or right)

blue_y

(float, -1 to 1) Shift the Blue Y coordinates (up or down)

green_x

(float, -1 to 1) Shift the Green X coordinates (left or right)

green_y

(float, -1 to 1) Shift the Green Y coordinates (up or down)

red_x

(float, -1 to 1) Shift the Red X coordinates (left or right)

red_y

(float, -1 to 1) Shift the Red Y coordinates (up or down)

Crop

Crop out any part of a video clip. This effect is the primary method for cropping a Clip in OpenShot. The left, right, top, and bottom key-frames can even be animated, for a moving and resizing cropped area. You can leave the cropped area blank, or you can dynamically resize the cropped area to fill the screen.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

bottom

(float, 0 to 1) Size of bottom bar

left

(float, 0 to 1) Size of left bar

right

(float, 0 to 1) Size of right bar

top

(float, 0 to 1) Size of top bar

x

(float, -1 to 1) X-offset

y

(float, -1 to 1) Y-offset

resize

(bool, choices: ['Yes', 'No']) Replace the frame image with the cropped area (allows automatic scaling of the cropped image)

Deinterlace

Remove interlacing from a video (i.e. even or odd horizontal lines)

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

isOdd

(bool, choices: ['Yes', 'No']) Use odd or even lines

Hue

Adjust the hue / color of the frame’s image.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

hue

(float, 0 to 1) The curve to adjust the percentage of hue shift

Negative

Negates the colors, producing a negative of the image.

Object Detector

Detect objects through the video.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

class_filter

(string) Type of object class to filter (i.e. car, person)

confidence_threshold

(float, 0 to 1) Minimum confidence value to display the detected objects

display_box_text

(int, choices: ['Off', 'On']) Draw a rectangle around detected objects

objects

(list) List of detected object ids

selected_object_index

(int, 0 to 200) Index of the tracked object that was selected to modify its properties

Pixelate

Pixelate (increase or decrease) the number of visible pixels.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

bottom

(float, 0 to 1) The curve to adjust the bottom margin size

left

(float, 0 to 1) The curve to adjust the left margin size

pixelization

(float, 0 to 0.99) The curve to adjust the amount of pixelization

right

(float, 0 to 1) The curve to adjust the right margin size

top

(float, 0 to 1) The curve to adjust the top margin size

Shift

Shift the image up, down, left, and right (with infinite wrapping).

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

x

(float, -1 to 1) Shift the X coordinates (left or right)

y

(float, -1 to 1) Shift the Y coordinates (up or down)

Stabilizer

Stabilize video clip to remove undesired shaking and jitter.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

zoom

(float, 0 to 2) Percentage to zoom into the clip, to crop off the shaking and uneven edges

Tracker

Track the selected bounding box through the video. The tracked object can be selected as a parent on other clips. See Clip Parent.

Wave

Distort the frame’s image into a wave pattern.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

amplitude

(float, 0 to 5) The height of the wave

multiplier

(float, 0 to 10) Amount to multiply the wave (make it bigger)

shift_x

(float, 0 to 1000) Amount to shift X-axis

speed_y

(float, 0 to 300) Speed of the wave on the Y-axis

wavelength

(float, 0 to 3) The length of the wave

Audio Effects

Audio effects modify the waveforms and audio sample data of a clip. Below is a list of audio effects, and their properties. Often it is best to experiment with an effect, entering different values into the properties, and observing the results.

Compressor

Reduce the volume of loud sounds or amplify quiet sounds.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

attack

(float, 0.1 to 100)

bypass

(bool)

makeup_gain

(float, -12 to 12)

ratio

(float, 1 to 100)

release

(float, 10 to 1000)

threshold

(float, -60 to 0)

Delay

Adjust the synchronism between the audio and video track.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

delay_time

(float, 0 to 5)

Distortion

Alter the audio by clipping the signal.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

distortion_type

(int, choices: ['Hard Clipping', 'Soft Clipping', 'Exponential', 'Full Wave Rectifier', 'Half Wave Rectifier'])

input_gain

(int, -24 to 24)

output_gain

(int, -24 to 24)

tone

(int, -24 to 24)

Echo

Reflection of sound with a delay after the direct sound.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

echo_time

(float, 0 to 5)

feedback

(float, 0 to 1)

mix

(float, 0 to 1)

Expander

Louder parts of audio become relatively louder and quieter parts become quieter.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

attack

(float, 0.1 to 100)

bypass

(bool)

makeup_gain

(float, -12 to 12)

ratio

(float, 1 to 100)

release

(float, 10 to 1000)

threshold

(float, -60 to 0)

Noise

Random signal having equal intensity at different frequencies.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

level

(int, 0 to 100)

Parametric EQ

Filter that allows you to adjust the volume level of a frequency in the audio track.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

filter_type

(int, choices: ['Low Pass', 'High Pass', 'Low Shelf', 'High Shelf', 'Band Pass', 'Band Stop', 'Peaking Notch'])

frequency

(int, 20 to 20000)

gain

(int, -24 to 24)

q_factor

(float, 0 to 20)

Robotization

Transform the voice present in an audio track into a robotic voice effect.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

fft_size

(int, choices: ['128', '256', '512', '1024', '2048'])

hop_size

(int, choices: ['1/2', '1/4', '1/8'])

window_type

(int, choices: ['Rectangular', 'Bart Lett', 'Hann', 'Hamming'])

Whisperization

Transform the voice present in an audio track into a whispering voice effect.

Property Name

Description

apply_before_clip

(bool, choices: ['Yes', 'No']) Apply this effect before the Clip processes keyframes? (default is Yes)

fft_size

(int, choices: ['128', '256', '512', '1024', '2048'])

hop_size

(int, choices: ['1/2', '1/4', '1/8'])

window_type

(int, choices: ['Rectangular', 'Bart Lett', 'Hann', 'Hamming'])

For more info on key frames and animation, see Animation.
